INVENTOR System of Base - Training by stigcad

Base Training and Advanced Training

These trainings are intended to offer all the tools of INVENTOR a designer will need to create INVENTOR parts, assemblies and drawings for professional production. Besides the basic tools the trainees will get an overview about sheet metal - design, weldments and even parametrical layout design o Content stigcad offers a well approved system of Base - Training for the autodesk INVENTOR. The Base - system consists of two parts: Base Training Advanced Training for those who have already attended Base-Training or are experienced in Inventor basics o Duration Each training consists of 2 x 3 days within two weeks, Monday-Wednesday in first week and Wednesday-Friday in the second. This system offers the trainee the chance to practice using the tools and to have 4 days on duty even during the training period. o Cost Base Training: EUR 1385,- excl. VAT. / EUR 1.662,- incl. 20% VAT. / person- for further information, ask for an adjusted offer, please Advanced Training: EUR 1780,- excl. VAT. / EUR 2.136,- incl. 20% VAT. / person- for further information, ask for an adjusted offer, please and of course all these INVENTOR Base Trainings can be customised according to the individual needs of any company - Questions? - info@stigcad.at

INVENTOR Update - Training

stigcad supports the transfer to a more recent release of INVENTOR by offering special update trainings. The content is to be customised to the company`s needs in advance. Duration depends on customised content.

INVENTOR Special - Trainings

Sheet-Metal design

o Content the theoretical background of Sheet Metal modelling, explanation of the Sheet Metal Style, the different ways to design professional parametric Sheet Metal parts (direct modelling, Surface as dummy), sheet metal tools like flanges, corner seams, ..., flat pattern and creation of professional drawings for production o Duration 1,5 days o Cost 935,- excl. VAT. / 1.122,- incl. 20% VAT. / person for further information, feel free to ask for a personalized offer

Layout Design - Advanced Parametrical Design

o Content Layout Design is the most advanced design method in INVENTOR, starting with simple parameter driven parts the trainees will learn how to create complete parameter driven assemblies. One parameter part or layout part with parametric sketches drives all the parts’ dimensions and even their position in an assembly o Duration 1,5 days o Cost 935,- excl. VAT. / 1.122,- incl. 20% VAT. / person for further information, feel free to ask for personalized offer

Design Accelerator for creating elements for mechanical engineering (Frame Generator, Shaft Generator, ...)

o Content INVENTOR offers various tools to accelerate the calculation and creation of elements specific for mechanical engineering like shafts, frames, springs or screw / bolt - connections. These and a lot of more of these design tools will be this training`s topic. The designer will be able to use these tools to accelerate the creation of mechanical design o Duration 2 days o Cost 1.245,- excl. VAT. / 1.494,- incl. 20% VAT. / person for further information, feel free to ask for personalized offer

Dynamic Simulation in INVENTOR

o Content INVENTOR offers a tool to estimate the accelerations, velocities and the resulting forces in an assembly during movement. This training offers all the knowledge a designer needs to gather all the information needed for professional design. Trainees are invited to even bring their own problems to be discussed. o Duration 2 days o Cost 1.245,- excl. VAT. / 1.494,- incl. 20% VAT. / person - for further information, feel free to ask for personalized offer

Visualisation in INVENTOR - “creating real life pictures of design”

o Content this training offers all the knowledge to create professional visualisations of parts or assemblies in INVENTOR. Background information about materials and their occurrence to put your design in perspective! o Duration 1,5 days o Cost 935,- excl. VAT. / 1.122,- incl. 20% VAT. / person for further information, feel free to ask for a personalized offer and of course all these INVENTOR Special Trainings can be customised according to the individual needs of any company - Questions? - info@stigcad.at

INVENTOR Special - Trainings for “NON” - Designers

stigcad SPECIALITY - The „INVENTOR Viewer“ - Training

o Content Persons who are not involved in the design process but need to know what’s going on, or wish to just open part / assembly files in order to get some information about dimensions, material or other physical properties. Sometimes it is helpful to prepare some datasets to be used in discussions or in meetings. This training offers all the tools for opening part / assembly files, measuring dimensions, creating sections or doing some simple drawings with views / section views of a design. o Duration 1,5 days o Cost 935,- excl. VAT. / 1.122,- incl. 20% VAT. / person for further information, ask for an adjusted offer

INVENTOR Administration

o Content In order to implement a “company‘s-standard” it is necessary to customise INVENTOR to the individual requirements. This training shows how to adjust the templates regarding the standards used in a company. Preferably this training is to be held in-house, in order to implement the modifications directly: materials, occurrence and light, dimension- and text styles, layers - understanding the usage of the “style table” o Duration 1 day without modifications / starting with 2 days including user / company defined modifications of the INVENTOR environment o Cost 675,- excl. VAT. / 810,- incl. 20% VAT. / person for further information, ask for an adjusted offer and of course all these INVENTOR Spezial Trainings for “NONE” - Designers can be customised according to the individual needs of any company - Questions? - info@stigcad.at
